40w Ip65 Batten Light Dimmable Led Batten Lights Waterproof LED Linear Light 150LM/W

40w Ip65 Batten Light Dimmable Led Batten Lights Waterproof LED Linear Light 150LM/W

40w Ip65 Batten Light

40w Dimmable Led Batten Lights

waterproof Ip65 Batten Light

Place of Origin:

China

Brand Name:

X-Power

Certification:

CE ROHS SAA PSE ETL

Model Number:

XP-PL3040

Document:

150LM LED Tri-proof Light N...ew.pdf

Chat Now
Request A Quote
40w Ip65 Batten Light Dimmable Led Batten Lights Waterproof LED Linear Light 150LM/W
40w Ip65 Batten Light Dimmable Led Batten Lights Waterproof LED Linear Light 150LM/W 40w Ip65 Batten Light Dimmable Led Batten Lights Waterproof LED Linear Light 150LM/W 40w Ip65 Batten Light Dimmable Led Batten Lights Waterproof LED Linear Light 150LM/W 40w Ip65 Batten Light Dimmable Led Batten Lights Waterproof LED Linear Light 150LM/W
Product Details
Features:
IP65& Dustproof & Corrosion-proof
Material:
PVC+Aluminum+PMMA
Power:
40W/30W/20W Switchable
Lighting Effect:
150LM/W
RA:
>80
Warranty:
5 Years
IP Grade:
IP65
Multi-function Optional:
Dimming /Sensor/Emergency/
Highlight:

40w Ip65 Batten Light

,

40w Dimmable Led Batten Lights

,

waterproof Ip65 Batten Light

Payment & Shipping Terms
Minimum Order Quantity
1pcs
Price
14.9USD/pcs
Packaging Details
Carton
Delivery Time
7-15working days
Payment Terms
TT
Supply Ability
50000pcs per month
RELATED PRODUCTS
Good price 40w Ip65 Batten Light Dimmable Led Batten Lights Waterproof LED Linear Light 150LM/W online Video

40w Ip65 Batten Light Dimmable Led Batten Lights Waterproof LED Linear Light 150LM/W

Chat Now
Good price Customized Led Batten Strip Lights Non Corrosive Led Batten IP65 For Industrial online Video

Customized Led Batten Strip Lights Non Corrosive Led Batten IP65 For Industrial

Chat Now
Good price Waterproof 2ft LED Batten Light Fluorescent Light Fixture With Switchable CCT Power online Video

Waterproof 2ft LED Batten Light Fluorescent Light Fixture With Switchable CCT Power

Chat Now
Contact Us
13590447317
Hedy.yin@x-power.cc
86--13590447317
Chat Now
Product Description
40W Waterproof LED Linear Light Fixture with 150LM/W
Product Attributes
Attribute Value
Material PVC+Aluminum+PMMA
Power 40W/30W/20W Switchable
Lighting effect 150LM/W
RA >80
Warranty 5 years
IP Grade IP65
Features IP65 & Dustproof & Corrosion-proof
Multi-function optional Dimming / Sensor / Emergency
Product Specifications
Model No XP-PL3010 XP-PL3020 XP-PL3030 XP-PL3040 XP-PL3050 XP-PL3060 XP-PL3080
Size(mm) 300x124x43 640x124x43 900x124x43 1200x124x43 1500x124x43 1500x124x43 1800x124x43
Power 10W 20W 30W 40W 50W 60W 80W
LED Chip SMD2835
Input Voltage 85-265VAC/100-277VAC
Power Frequency 50/60Hz
Power Factor 0.9
LED Lum. Efficiency 150LM/W
CCT 5800-6100K(CW), 4000-4200K(NW), 3000-3150(WW)
CRI Ra>80
LED Node Temperature ≦55℃
Operation Ambient Temperature -20-45℃
Storage Temperature -25-50℃
IP Grade IP65
Color Tolerance Adjustment 5SDCM
Power supply Build-in
Housing Color Optional White/Black/Silver/Gold
Certification PSE&SAA&CE&ROHS&ETL&DLC
Key Features
  • High light source efficiency and constant current output design, greatly extends the lighting fixture's lifespan
  • Ultra slim, all-in-one design with high-quality silicon rubber sealing ring for excellent IP65 performance
  • PVC body + PMMA cover + Aluminum mainboard with low current consumption for perfect heat dissipation, safety and reliability
  • Integrated streamline light source structure provides even and soft light distribution
Packing Details
Model Dimensions Inner Box Net/Gross Weight Carton Carton Weight
XP-PL3010 300*120*40mm 1pc/Inner Box: 35*13.5*5cm NW:0.8kg GW:0.9kg 12pcs/Carton: 70.5*28.5*16.5cm NW:7.2kg GW:10.5kg
XP-PL3020 600*120*40mm 1pc/Inner Box: 69*13.5*5cm NW:1.2kg GW:1.4kg 6pcs/Carton: 70.5*28.5*16.5cm NW:7.2kg GW:9.5kg
XP-PL3030 1200*120*40mm 1pc/Inner Box: 125*13.5*5cm NW:2.3kg GW:2.6kg 6pcs/Carton: 132.2*28.5*16.5cm NW:13.8kg GW:17kg
XP-PL3040 1200*120*40mm 1pc/Inner Box: 125*13.5*5cm NW:2.3kg GW:2.6kg 6pcs/Carton: 132.2*28.5*16.5cm NW:13.8kg GW:17kg
XP-PL3050 1500*120*40mm 1pc/Inner Box: 155*13.5*5cm NW:2.8kg GW:3.2kg 6pcs/Carton: 162.2*28.5*16.5cm NW:16.2kg GW:21kg
XP-PL3060 1500*120*40mm 1pc/Inner Box: 155*13.5*5cm NW:2.8kg GW:3.2kg 6pcs/Carton: 162.2*28.5*16.5cm NW:16.2kg GW:21kg
Frequently Asked Questions
Are you professional manufacturer in LED tri-proof light?
Yes, we focus on LED tri-proof light with our patent design, making us 100% professional in this field.
What is your LED chips? Efficiency? CRI and CCT?
A1: We use Epistar2835 chips
A2: Our finished lights efficiency is 100lm/w, with options for 110lm/w, 120lm/w, 140lm/w and 150lm/w
A3: Standard Ra>80, with optional CCT (CW/NW/WW)
Do you have any certification for your lights?
Yes, we have UL DLC CE, RoHS, SAA, PSE, TUV CE, IP65 report, and Ammonia test report.
Do you have any multi-function tri-proof lights?
Yes, we offer various multi-function options:
A1: Emergency function with battery backup for at least 3 hours
A2: Triac dimming & 0-10v dimming function
A3: Microwave sensor function
A4: Series connection capability
What are your main markets?
Europe, South America, Mid-East, Southeast Asia, South Africa, Australia, etc.
Do you accept smaller trial orders?
Yes, we support smaller orders and provide maximum support.
How is your delivery time?
Samples: 3-5 days; Bulk orders: approximately 10 days.
What are your payment terms?
A1. Samples: 100% TT payment in advance
A2. Bulk order: 30% deposit and 70% balance before shipment
